The VB series is based on the horizontal packaging machine and is combined with a double-chamber box-type vacuum equipment to achieve fully automatic vacuum bag packaging of products.
Zipper closure
1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in
place during workout
Main standard features
Intelligent and efficient, energy-saving and consumption-reducing
The whole machine has a high degree of automation. Only one person is needed to complete the entire process from film winding and bag making, precise filling, efficient vacuuming, heat sealing to finished product output. The integrated design significantly reduces the reliance on manual labor, effectively saves packaging material waste and labor costs, and realizes intensive production.
Stable performance and outstanding production capacity
Equipped with a full servo dual-chamber structure, the two chambers alternate operations, ensuring not only smooth and reliable operation but also achieving an efficient continuous production of over 100 bags per minute. This significantly boosts the production capacity per unit time, meeting the demands of large-scale orders.
Continuous vacuuming system, highly efficient and stable
The core of the system adopts high-performance vacuum pumps of German brands, featuring fast pumping speed and stable vacuum degree, ensuring that all kinds of product packaging reach an excellent vacuum state. The continuous vacuuming working mode seamlessly connects with the production rhythm, eliminates efficiency bottlenecks, and significantly improves the overall packaging efficiency.
The whole machine has a high degree of automation. Only one person is needed to complete the entire process from film winding and bag making, precise filling, efficient vacuuming, heat sealing to finished product output. The integrated design significantly reduces the reliance on manual labor, effectively saves packaging material waste and labor costs, and realizes intensive production.
Stable performance and outstanding production capacity
Equipped with a full servo dual-chamber structure, the two chambers alternate operations, ensuring not only smooth and reliable operation but also achieving an efficient continuous production of over 100 bags per minute. This significantly boosts the production capacity per unit time, meeting the demands of large-scale orders.
Continuous vacuuming system, highly efficient and stable
The core of the system adopts high-performance vacuum pumps of German brands, featuring fast pumping speed and stable vacuum degree, ensuring that all kinds of product packaging reach an excellent vacuum state. The continuous vacuuming working mode seamlessly connects with the production rhythm, eliminates efficiency bottlenecks, and significantly improves the overall packaging efficiency.
Packaging formats
Technical specifications
| Model | VBS-180Z (S-180Z + VPB1710) |
VBS-180D (S-180D + VPB1710D) |
VBSG-180Z (SG-180Z + VPB1710) |
VBSG-180D (SG-180D+ VPB1710D) |
| Dimensions L*W*H | 6810*970*1500mm | 5650*970*1500mm | 4150*970*1390mm | 4140*970*1390mm |
| Equipment weight | 2500kg | 2100kg | 1400kg | 1300kg |
| Working power supply | AC380V 50Hz | AC380V 50Hz | AC380V 50Hz | AC380V 50Hz |
| Input power | 13Kw | 11.5Kw | 8.8Kw | 8.8Kw |
| Working Air Current | 0.5MPa | 0.5MPa | 0.5MPa | 0.5MPa |
| Air consumption | 400NL/min | 400NL/min | 500NL/min | 500NL/min |
| Packaging speed | 40~80ppm | 100~120ppm | 40~60ppm | 100~120ppm |
| Bag width range | 60mm~180mm | 50mm~90mm | 60mm~180mm | 60mm~90mm |
| Bag height range | 80mm~200mm | 80mm~180mm | 80mm~200mm | 80mm~180mm |
| Maximum packing volume | 400ml | 100ml | 500ml | 100ml |
Application
Full Automatc Premade zipper pouch packing machines are utilized in a multitude of industries for various products:
Food and Beverage: Packaging for snacks, coffee, tea, spices, pet food, frozen foods, and sauces.
Pharmaceuticals: For tablets, capsules, and powders.
Cosmetics: Packaging for creams, lotions, and gels.
Chemicals: For detergents, fertilizers, and other household or industrial products.
Food and Beverage: Packaging for snacks, coffee, tea, spices, pet food, frozen foods, and sauces.
Pharmaceuticals: For tablets, capsules, and powders.
Cosmetics: Packaging for creams, lotions, and gels.
Chemicals: For detergents, fertilizers, and other household or industrial products.
How It Work？
