Standard Premade stand up pouch packaging machine

Shanghai Acepack Intelligent Technology Co., Ltd. is one of the toppest Standard Premade stand up pouch packaging machine,Standard in China.During these years of exporting , Shanghai Acepack Intelligent Technology Co., Ltd. now has rich experience in the worldwide markets

Share This Product:

Product Description

1.Premade Pouch Stack 2.Flip-Out Pouch-Picking Unit 3.Pouch Opening 4.Air Flushing 5.Filling I 6.Filling II 7.Pouch Stretching 8.Top Seal 9.Finished Product 10.Outlet

Technical Parameter

model	SG-180	SG-210	SG-240	SG-280	SG-320
Pouch Size	60mmX 80mm(Min.) 180mmX 310mm(Max.)	90mmX 110mm(Min.) 210mmX 310mm(Max.)	100mmX 120mm(Min.) 240mmX 320mm(Max.)	90mmX 120mm(Min.) 280mmX 400mm(Max.)	140mmX 180mm(Min.) 320mmX 410mm(Max.)
Filling Capacity	1200mL	1600mL	2000mL	3000mL	4000mL
Packaging Speed	30-60ppm	30-60ppm	30-60ppm	30-60ppm	5-15ppm
Power	1.8kw	2.8kw	3.4kw	5.5kw	2.5kw
Air Consumption	200NL/min	200NL/min	400NL/min	400NL/min	300NL/min
Machine Dimensions	1900mm(L) 970mm(W) 1390mm(H)	2700mm(L) 970mm(W) 1400mm(H)	3100mm(L) 1010mm(W) 1400mm(H)	4100mm(L) 1020mm(W) 1500mm(H)	1800mm(L) 600mm(W) 1450mm(H)
Weight	700kg	900kg	1700kg	1800kg	600kg
Function	Flat Pouch, Doy Pack	Flat Pouch, Doy Pack	Flat Pouch, Doy Pack	Flat Pouch, Doy Pack	Flat Pouch, Doy Pack

Finished Bag Photo
