Zipper

Home > Products > Doypack Packing Machine > Zipper

Zipper

From inquiry to clients’ usage of Shanghai Acepack Intelligent Technology Co., Ltd.’sZipper , we promise to offer you superior service .Please believe your choice . Zipper

Share This Product:

Product Description

1.Zipper Release 2.Film Unwind 3.Bottom Holes Punching 4.Bag Forming 5.Film Guide 6.Horizontal Zipper Seal 7.Bottom Seal 8.Vertical Zipper Seal 9.Vertical Seal I 10.Vertical Seal II 11.Tear Notch 12.Photocell 13.Servo Advance 14.Cutting 15.Pouch Catching 16.Pouch Opening 17.Air Flushing 18.Filling I 19.Filling II 20.Pouch Stretching 21.Top Seal I 22.Top Seal II 23.Finished Product 24.Outlet

Technical Parameter

Modle	DS-140SZ	DS-180SZ	DS-240SZ	DS-280DSZ
Pouch Size	6090mm（Min） 140225mm(Max)	90110mm（Min） 180260mm(Max)	100120mm（Min） 240320mm(Max)	90110mm（Min） 140250mm(Max)
Filling capacity	500ml	1200ml	2000ml	600ml
Packing capacity	50-80ppm	40-60ppm	30-60ppm	80-120ppm
Powder	8KW	8KW	10kw	12KW
Air consumption	200NL/min	200NL/min	300NL/min	400NL/min
Machine Dimensions	4780mm(L) 970mm(W) 1500mm(H)	6450mm(L) 1100mm(W) 1400mm(H)	7500mm(L) 1250mm(W) 1550mm(H)	7800mm(L) 1100mm(W) 1400mm(H)
Weight	1800kg	2300kg	2800kg	3400kg
Function	Flat pouch, Doypack, Zipper	Doypack, Shape, Hanging Hole,Zipper	Doypack, Shape, Hanging Hole, Zipper	Doypack, Shape, Hanging Hole

Finished Bag Photo
